Zpot-Laser-R

Lineer Luminaires

ZPOT LASER R


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
(4000K)
Dimensions (wxhxl)
Source
Color Temperature
ZPOT LASER R
10W
900 lm
45x43x120 mm
LED
2700K/3000K/4000K/6500K
21W
1850 lm
45x43x320 mm
2700K/3000K/4000K/6500K

Specification


  • Recessed mounting
  • Optic: 10°,16°,18°,25°, 30°, 40°,60° (35°+15° Oval Beam, 45°+15° Oval Beam)

Options


  • 1-10V Dimmable, DALI Dimmable
  • 1-3 Hour Emergency Kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/zpot-laser-r/feed/ 0 Aero Wide R https://www.zlux.com/en/zlux-lighting/aero-wide-r/ https://www.zlux.com/en/zlux-lighting/aero-wide-r/#respond Wed, 20 May 2020 12:27:07 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1496

Lineer Luminaires

AERO WIDE R


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Source
Color Temperature
AERO WIDE R
24W/m
2400lm
H : 92mm
W : 216mm
LED
2700K/3000K/4000K/6500K
48W/m
4800lm

Specification


  • Recessed mounting
  • Optic: PMMA Opal Diffuser
  • Lenght: As Required
  • Body: Anodized Aluminium

Options


  • ON/OFF or DALI Dimmable
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-wide-r/feed/ 0 Aero R https://www.zlux.com/en/zlux-lighting/aero-r/ https://www.zlux.com/en/zlux-lighting/aero-r/#respond Wed, 20 May 2020 12:00:20 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1489

Lineer Luminaires

AERO R


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Length (L)
Source
Color
Temperature
AERO FIT-R/HE
10W
1300lm
H : 105mm
W : 106mm
560mm
LED
2700K/3000K/4000K/6500K
14W
1800lm
840mm
19W
2470lm
1260mm
25W
3250lm
1540mm


AERO FIT-R/HO
14W
1600lm
560mm
21W
2400lm
840mm
30W
3450lm
1260mm
37W
4250lm
1540mm

Specification


  • Recessed mounting
  • Optic: Opal Diffuser
  • Aluminium Body With Electrostatic Paint
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • 1-3 Hour emergency kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-r/feed/ 0 Aero Fit R DA https://www.zlux.com/en/zlux-lighting/aero-fit-r-da/ https://www.zlux.com/en/zlux-lighting/aero-fit-r-da/#respond Wed, 20 May 2020 11:48:18 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1483

Lineer Luminaires

AERO FIT-R DA


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Length (L)
Source
Color Temperature
AERO FIT-R/HE
10W
1300lm
H : 90mm
W : 68,50
580mm
LED
2700K/3000K/4000K/6500K
14W
1800lm
860mm
19W
2470lm
1140mm
25W
3250lm
1420mm


AERO FIT-R/HO
14W
1600lm
580mm
21W
2400lm
860mm
30W
3450lm
1140mm
37W
4250lm
1420mm

Specification


  • Recessed mounting
  • Optic: Lens
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • 1-3 Hour emergency kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-fit-r-da/feed/ 0 Aero Fit R A https://www.zlux.com/en/zlux-lighting/aero-fit-r-a/ https://www.zlux.com/en/zlux-lighting/aero-fit-r-a/#respond Wed, 20 May 2020 11:45:38 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1477

Lineer Luminaires

AERO FIT-R A


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Length (L)
Source
Color Temperature
AERO FIT-R/HE
10W
1300lm
H : 90mm
W : 68,50mm
580mm
LED
2700K/3000K/4000K/6500K
14W
1800lm
860mm
19W
2470lm
1140mm
25W
3250lm
1420mm


AERO FIT-R/HO
14W
1600lm
580mm
21W
2400lm
860mm
30W
3450lm
1140mm
37W
4250lm
1420mm

Specification


  • Recessed mounting
  • Optic: Lens
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • 1-3 Hour emergency kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-fit-r-a/feed/ 0 Aero Fit R T90 https://www.zlux.com/en/zlux-lighting/aero-fit-r-t90/ https://www.zlux.com/en/zlux-lighting/aero-fit-r-t90/#respond Wed, 20 May 2020 11:41:14 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1471

Lineer Luminaires

AERO FIT-R T90


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Length (L)
Source
Color Temperature
AERO FIT-R/HE
10W
1300lm
H : 90mm
W : 68,50
580mm
LED
2700K/3000K/4000K/6500K
14W
1800lm
860mm
19W
2470lm
1140mm
25W
3250lm
1420mm


AERO FIT-R/HO
14W
1600lm
580mm
21W
2400lm
860mm
30W
3450lm
1140mm
37W
4250lm
1420mm

Specification


  • Recessed mounting
  • Optic: Lens
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • 1-3 Hour emergency kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-fit-r-t90/feed/ 0 Aero Fit R T60 https://www.zlux.com/en/zlux-lighting/aero-fit-r-t60/ https://www.zlux.com/en/zlux-lighting/aero-fit-r-t60/#respond Wed, 20 May 2020 11:37:27 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1466

Lineer Luminaires

AERO FIT-R T60


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Length (L)
Source
Color Temperature
AERO FIT-R/HE
10W
1300lm
H : 90mm
W : 68,50
580mm
LED
2700K/3000K/4000K/6500K
14W
1800lm
860mm
19W
2470lm
1140mm
25W
3250lm
1420mm


AERO FIT-R/HO
14W
1600lm
580mm
21W
2400lm
860mm
30W
3450lm
1140mm
37W
4250lm
1420mm

Specification


  • Recessed mounting
  • Optic: Lens
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • 1-3 Hour emergency kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-fit-r-t60/feed/ 0 Aero Fit R T0 https://www.zlux.com/en/zlux-lighting/aero-fit-r-t0/ https://www.zlux.com/en/zlux-lighting/aero-fit-r-t0/#respond Wed, 20 May 2020 11:26:30 +0000 http://www.zlux.com/en/?post_type=portfolio&p=1453

Lineer Luminaires

AERO FIT-R T0


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions
Length (L)
Source
Color Temperature
AERO FIT-R/HE
10W
1300lm
H : 90mm
W : 68,50
580mm
LED
2700K/3000K/4000K/6500K
14W
1800lm
860mm
19W
2470lm
1140mm
25W
3250lm
1420mm


AERO FIT-R/HO
14W
1600lm
580mm
21W
2400lm
860mm
30W
3450lm
1140mm
37W
4250lm
1420mm

Specification


  • Recessed mounting
  • Optic: Lens
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • 1-3 Hour emergency kit
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features


]]> https://www.zlux.com/en/zlux-lighting/aero-fit-r-t0/feed/ 0 Aero Fit R https://www.zlux.com/en/zlux-lighting/aero-fit-r/ https://www.zlux.com/en/zlux-lighting/aero-fit-r/#respond Tue, 10 Mar 2020 11:50:14 +0000 http://www.zlux.com/en/?post_type=portfolio&p=604
AERO FIT-R White

Lineer Luminaires

AERO FIT-R


Advances in technology mean that lumen outputs are continuosly increasing. The figures above are corrent at time print. Please reach our sales team for up to date information.


Model
Power
Lumen Output
Dimensions (axbxh)
Source
Color Temperature
AERO FIT-R/HE
10W
1070 lm
68,50x560x73,40 mm
LED
2700K/3000K/4000K/6500K
14W
1600 lm
68,50x560x73,40 mm
2700K/3000K/4000K/6500K
19W
2120 lm
68,50x1260x73,40 mm
2700K/3000K/4000K/6500K
25W
2660 lm
68,50x1540x73,40 mm
2700K/3000K/4000K/6500K


AERO FIT-R/HO
14W
1845 lm
668,50x560x73,40 mm
2700K/3000K/4000K/6500K
21W
2800 lm
68,50x840x73,40 mm
2700K/3000K/4000K/6500K
30W
3690 lm
68,50x1260x73,40 mm
2700K/3000K/4000K/6500K
37W
4600 lm
68,50x1540x73,40 mm
2700K/3000K/4000K/6500K

Specification


  • Recessed mounting
  • Optics: Opal diffuser
  • Body: Anodized aluminium
  • 220-240V 50/60 Hz

Options


  • Current,1-10V Dimmable, DALI Dimmable
  • Motion sensor
  • Daylight sensor
  • 1-3 Hour emergency kit
  • Surface mounting case
  • IP20

Color


White Black Gray

Applications


Hotels, Shopping malls, Office, General commercial projects

Features
